Self-assembled F450 - What is the picture transmission: An inventory of recent hot topics and hot content
Recently, there has been a surge in discussions in the drone enthusiast community about setting up a self-assembled F450 with an image transmission system. This article will combine the hot topics and hot content on the Internet in the past 10 days to sort out relevant technical points and market dynamics, and provide structured data for reference.
1. Top 5 recent hot topics in the drone field
| Ranking | topic | Discussion popularity | Main platform |
|---|---|---|---|
| 1 | F450 Rack Assembly Guide | ★★★★★ | Station B, Zhihu |
| 2 | Comparison of 5.8G image transmission systems | ★★★★☆ | Drone forums and posts |
| 3 | Open source flight control options | ★★★★ | GitHub、CSDN |
| 4 | FPV glasses purchase | ★★★☆ | E-commerce platform comment area |
| 5 | Interpretation of new drone regulations | ★★★ | Government official website, news media |
2. Comparison of popular image transmission systems assembled in F450
According to actual measurement data from recent technology forums, the following are the three most popular image transmission solutions:
| Model | Transmission distance | delay | Power consumption | reference price |
|---|---|---|---|---|
| Rush Tank II | 5km | 30ms | 800mW | ¥580 |
| Eachine TX805 | 3km | 50ms | 600mW | ¥320 |
| TBS Unify Pro32 | 8km | 25ms | 1W | ¥850 |
3. Assembly suggestions and techniques
1.Antenna selection: It is recommended to use a mushroom antenna or a flat antenna, which can increase the transmission distance by 20%-30%.
2.Power supply solution: Most video transmission systems support 7-24V wide voltage input and can draw power directly from the flight controller.
3.Heat dissipation treatment: High-power image transmission requires the installation of a heat sink to avoid performance degradation caused by long-term operation.
4.Frequency band selection: In the 5.8G frequency band, it is recommended to avoid the commonly used channels 1-8 and choose Raceband to reduce interference.
4. Recent price trends of popular accessories
| Accessory type | Average price change | Popular models |
|---|---|---|
| Image transmission transmitter | ↓5.2% | Rush Tank Series |
| FPV camera | ↑3.8% | Foxeer Predator |
| receiver | Basically the same | RapidFire |
| antenna | ↓8.5% | LumenierAXII |
5. Technology Trend Forecast
1.Popularization of digital image transmission: The price of DJI HD systems continues to drop, which may impact the traditional analog video transmission market.
2.Integrated design: The new generation of flight controllers begins to integrate image transmission control functions to simplify wiring complexity.
3.regulatory impact: Some areas have begun to restrict the use of high-power image transmission. It is recommended to pay attention to local policies.
4.Open source ecosystem: The cheap image transmission solution based on ESP32 has gained attention in the open source community.
6. Frequently Asked Questions for Newbies
Q: How much power of image transmission is required for F450 assembly?
A: Generally, 600mW is enough for use within 2km, and 800mW or more is recommended for longer than 3km.
Q: What should I do if the video transmission signal is interfered with?
A: You can try changing the frequency band, using high-quality feeders, or upgrading to a diversity receiving system.
Q: How to judge the quality of image transmission?
A: Key observations: 1) Snowflake level 2) Delay 3) Signal recovery speed 4) Anti-interference ability.
From the above analysis, it can be seen that the self-assembled F450 paired with a suitable image transmission system is still one of the most cost-effective FPV solutions. It is recommended that users choose the most suitable configuration solution based on actual needs and budget.
